| الـ MOQ: | 1 |
| السعر: | قابل للتفاوض |
| التعبئة القياسية: | حالة الخشب الرقائقي |
| فترة التسليم: | 40 يوما |
| طريقة الدفع او السداد: | تي/تي |
| القدرة على التوريد: | 1 مجموعة في الشهر |
| Parameter | Details |
|---|---|
| Power Supply | Single-phase AC 220V / 50Hz |
| Air Supply | 0.6 MPa |
| Control System | PLC + Industrial PC |
| Barcode/QR Code | Integrated scanner with test data traceability |
| Continuity & Wiring | PLC I/O scanning with auto pass/fail judgment |
| Built-in Resistance | Range: 1-5000 Ω, Accuracy: ±1% |
| CC & PE Resistance | Supports 16A/32A/63A AC plugs; accuracy: 1-2% |
| Thermistor Test | Range: 100-50,000 Ω, Accuracy: ±2% |
| Voltage Drop Test | Adjustable three-phase transformer: 0-380V, load 0-35A |
| Insulation Resistance | Test voltage: DC 100-1000V adjustable; lower limit: 1MΩ-1GΩ |
| Dielectric Strength | AC 0-5kV / DC 0-6kV; leakage current monitoring |
| Test Station | Single station, one product per test |
| Plug Holders | EU (vehicle & pedestal), GB, US AC holders |
| Socket Height | 750-1000 mm, ergonomic design |
| Software | Windows 7/10 compatible with data export capabilities |
| Dimensions | W 900 × D 800 × H 1800 mm |
| Weight | Approx. 300 kg |
| Mobility | Lockable casters |
| MES Connectivity | Optional (additional cost) |
فيديو
فيديو
فيديو
فيديو
فيديو
|
|
| الـ MOQ: | 1 |
| السعر: | قابل للتفاوض |
| التعبئة القياسية: | حالة الخشب الرقائقي |
| فترة التسليم: | 40 يوما |
| طريقة الدفع او السداد: | تي/تي |
| القدرة على التوريد: | 1 مجموعة في الشهر |
| Parameter | Details |
|---|---|
| Power Supply | Single-phase AC 220V / 50Hz |
| Air Supply | 0.6 MPa |
| Control System | PLC + Industrial PC |
| Barcode/QR Code | Integrated scanner with test data traceability |
| Continuity & Wiring | PLC I/O scanning with auto pass/fail judgment |
| Built-in Resistance | Range: 1-5000 Ω, Accuracy: ±1% |
| CC & PE Resistance | Supports 16A/32A/63A AC plugs; accuracy: 1-2% |
| Thermistor Test | Range: 100-50,000 Ω, Accuracy: ±2% |
| Voltage Drop Test | Adjustable three-phase transformer: 0-380V, load 0-35A |
| Insulation Resistance | Test voltage: DC 100-1000V adjustable; lower limit: 1MΩ-1GΩ |
| Dielectric Strength | AC 0-5kV / DC 0-6kV; leakage current monitoring |
| Test Station | Single station, one product per test |
| Plug Holders | EU (vehicle & pedestal), GB, US AC holders |
| Socket Height | 750-1000 mm, ergonomic design |
| Software | Windows 7/10 compatible with data export capabilities |
| Dimensions | W 900 × D 800 × H 1800 mm |
| Weight | Approx. 300 kg |
| Mobility | Lockable casters |
| MES Connectivity | Optional (additional cost) |
